Oil-water separator AUS-J03

The stainless steel grease separator is a high-performance, corrosion-resistant solution designed to efficiently remove fats, oils, and grease (FOG) from wastewater. Built with SUS304/316 stainless steel, it ensures durability and compliance with commercial and industrial hygiene standards.

Key Features:
✔ Advanced Separation
- Uses gravity separation + baffle technology to trap ≥90% of FOG (up to 98% for emulsified oils with optional air flotation).
- Oil droplet removal: Captures particles as small as 20μm (upgradable to 10μm with coalescing plates).
✔ Smart & Low-Maintenance
- Auto-skimming option (rotating paddles or timed pumps).
- Heated collection chamber (40-50°C) to prevent grease solidification in cold climates.
- Removable sludge drawer for easy cleaning.
✔ Compact & Durable
- Space-saving vertical design (30% smaller footprint than concrete interceptors).
- Full stainless construction resists corrosion from salt, acids, and cleaning chemicals.
Technical Specs:
Model Capacity (m³/h) Oil Removal Rate Discharge Standard Power
J03-1M 0.5-1 85-90% ≤50mg/L 0.2kW
J03-5M 1-5 92-95% ≤20mg/L 1.5kW
J03-10M 10-50 ≥98% ≤5mg/L 15kW
Ideal for:
- Commercial kitchens (restaurants, hotels, schools)
- Food processors (meat/poultry plants, dairy facilities)
- Industrial sites (garages, workshops with oil-bearing wastewater)
Why Choose This Model?
→ Longer lifespan than plastic/concrete units (10+ years with minimal maintenance).
→ Hygienic smooth surfaces pass FDA/CE sanitation audits.
→ Customizable with add-ons:
- Oil sensor alarms
- Integrated waste grinders
- Mobile skid-mounted versions
Compliance: Meets EN 1825, ASME A112.14.3, and GB 8978-1996 standards.
